BX Series

BX Series asynchronous motors with aluminum frames are the right solution for a wide range of general purpose industrial applications. Both the IEC and Compact motor are available in IE3 efficiency classes according to the international standard IEC 60034-30. Furthermore, Bonfiglioli's e-motors can be equipped with several options: protection class up to IP 56, tropicalized, corrosion-resistant paint, and anti-condensation heaters. Moreover, the BN/M and BX/MX motor Series are also able available in the BrakeMotor version with a selection of AC or DC brakes. To maximize our e-motor flexibility, all of them can be controlled with inverters.

Key features

Specifications

Degree of protection

Standard IP55
Standard for brake motors IP54

Mounting options

IM B3
IM B5
IM B14

Output

IEC

Motors

3 phase asynchronous

Specifications

Key benefits
- Reduced operating cost
- Energy saving
- Compliant to all the MEPS
- Complete (Gearbox + Motor) Solution
- Control flexibility
- Global motor (can be utilized in most of the markets)
Conformity
Efficiency - IEC 60034-30:2008
Low Voltage Directive - 2006/95/EC
Electromagnetic Compatibility
Directive - 2006/95/EC
Power range
Available voltages include
@50 Hz
230/400
290/500
400/690
290/500
@60 Hz
230/460
330/575
265/460
460/800
Brake options
Brake types:
AC & DC brakes

Brake-related options:
Manual release lever
Soft-start flywheel
Capacitive filter
Brake separate power supply
Brake functionality check (micro-switch)
Motor options
- Thermistors and thermostat sensors
- Independent forced cooling
- Incremental, sin/cos absolute single/multi-turn encoders
- Tropicalization
- Anti-condensate heaters
- Up to IP56 protection

Types & Powers

POWER RANGE

BX 90SR	0.75
BX 90S	1.1
BX 90LA	1.5
BX 100LA	2.2
BX 100LB	3
BX 112M	3.7
BX 132SB	5.5
BX 132MA	7.5
BX 160MB	11
BX 160L	15
BX 180M	18.5
BX 180L	22
