The Agile Series of inverters by Bonfiglioli sets new standards in technology for a broad range of users. Agile inverters are particularly suited for the food & beverage, textile, wood, packaging and ceramic industries, where they can be used in a variety of medium complexity automation processes.

Specifications

  • Types & powers (AGL402)

    Type | kW (three-phase)
    AGL402-02 1 | 0.25
    AGL402-03 1 | 0.37
    AGL402-05 1 | 0.55
  • Types & powers (AGL402)

    Type | kW (three-phase)
    AGL402-07 1 | 0.75
    AGL402-09 1 | 1.1
    AGL402-11 1 | 1.5
    AGL402-13 1 | 2.2
    AGL402-15 2 | 3.0
    AGL402-18 2 | 4.0
    AGL402-19 2 | 5.5
    AGL402-21 2 | 7.5
    AGL402-19 3 | 5.5
    AGL402-21 3 | 7.5
    AGL402-22 3 | 9.2
    AGL402-23 3 | 11
  • Types & powers (AGL202)

    Type | kW (three-phase)
    AGL202-02 1 | 0.25
    AGL202-03 1 | 0.37
    AGL202-05 1 | 0.55
    AGL202-07 1 | 0.75
    AGL202-09 1 | 1.1
    AGL202-11 1 | 1.5
    AGL202-13 1 | 2.2
    AGL202-15 2 | 3.0
    AGL202-18 2 | 4.0
    AGL202-19 3 | 5.5
    AGL202-21 3 | 7.5
  • Types & powers (AGL202)

    Type | kW (single-phase)
    AGL202-02 1 | 0.12
    AGL202-03 1 | 0.18
    AGL202-05 1 | 0.25
    AGL202-07 1 | 0.37
    AGL202-09 1 | 0.55
    AGL202-11 1 | 0.75
    AGL202-13 1 | 1.1
    AGL202-15 2 | 1.5
    AGL202-18 2 | 2.2
    AGL202-19 3 | 3
    AGL202-21 3 | 3
  • Main options

    Multmedia Card Slot
    • Slot for multimedia card for quick and easy copying


    Optional field bus communication:
    • CM-CAN: CANopen
    • CM-PDP-V1: PROFIBUS
    • CM232: Modbus ASCII & Modbus RTU for point-to-point connection
    • CM485: Modbus ASCII & Modbus RTU via RS485 connection
    • CM-DeviceNet: DeviceNet
    • CM-EtherCAT®: EtherCAT®
    • CM-PROFINET: PROFINET
    • CM-Ethernet/IP: Ethernet/IP with one usable port as end-of-line device
    • CM-Ethernet/IP-2P: Ethernet/IP with two usable ports (daisy chaining is possible)
    • CM-Modbus/TCP: Modbus/TCP with one usable port as end-of-line device
    • CM-Modbus/TCP-2P: Modbus/TCP with two usable ports (daisy chaining is possible)
    • Ethernet VABus/TCP: VABus/TCP: with one usable port as end-of-line device
    • Ethernet VABus/TCP-2P: VABus/TCP: with two usable ports (daisy chaining is possible)

    Optional interface for communication to PC
    • ASK-USB: Communication to PC via optional communication cable

    Optional PC software
    • VPlus for Windows operating system with motor setup, terminal monitor
    • Actual value window, scope function, parameter storage

    Accessories:
    • Brake resistors Type BR: The brake resistors offer an inexpensive solution to dissipate generator power that occurs at deceleration. A thermal sensor for the brake resistor protects the resistor from overheating.
    • Power choke type LCVS & LCVT: Power choke types LCVS (for single-phase power installation) and LCVT (for three-phase power installation) increase the overvoltage protection of the inverter and increase the system's EMC.
    • Power filters type FTV: Depending on the application boundaries, certain EMC levels must be achieved. The power filters are a component to improve EMC behavior in a machine installation.
  • Degree of protection

    IP20 (EN 60529)
  • Rated speed

    0 ... 599 Hz
  • Certifications

    UL508c
    STO (EN13849 / EN 61508)
  • Conformity

    CE
    EN61800
  • Power supply & Power range

    Power range (AGL402)
    0.25 - 11 kW / three-phase 320 V... 530 V / 50 - 60 Hz (± 10%)

    Power range (AGL202)
    0.12 - 3 kW / single-phase 200 V... 240 V / 50 - 60 Hz (± 10%)
    0.25 - 7.5 kW / three-phase 200 V ... 240 V / 50 - 60 Hz (± 10%)
  • Software features

    • Preset values for Bonfiglioli motors to decrease commissioning times
    • Flexible assignment of digital inputs and outputs
    • Energy Saving function
    • Ready to use application macros
    • Motor chopper function to increase braking power without brake resistors
    • Power failure regulation
    • Fault history
    • Motor and inverter state memory
    • Integrated PLC function with graphic development environment
  • Hardware features

    • Integrated Keypad
    • Integrated brake chopper
    • Integrated Safe Torque Off function
    • DC link connection
    • 6 digital inputs, 2 multifunction A/D inputs
    • 1 digital output, 1 multifunction I/O
    • 1 relay output, 1 multifunction A/D/Pulse output
    • Signal supply outputs: +24 V DC, + 10 V DC
    +24 V DC input for electronic power supply
    • Serial interfaces: RS-232, RS-485 including Modbus support
    system bus
  • Mounting options

    • Cabinet mounting for all sizes
    • Optional feed-through mounting
    • Optional DIN rail mounting frame size 1
    • Optional ColdPlate mounting
  • Motors

    • Motor compatibility
    • Two types of motors:
    • Asynchronous AC motors
    • Permanent magnet synchronous (brushless) motors
