Standard inverters, AGILE Series | India

Specifications

Main options
• Different Field bus options like CANopen, PROFIBUS, Modbus
• Optional accessories like brake resistor, mains chokes, mains filters
• Optional Connection set for connection to PC

Optional field bus communication:
- CM-CAN: CANopen
- CM-PDP-V1: PROFIBUS
- CM232: Modbus ASCII & Modbus RTU for point-to-point connection
- CM485: Modbus ASCII & Modbus RTU via RS485 connection
- CM-DeviceNet: DeviceNet
- CM-EtherCAT®: EtherCAT®
- CM-PROFINET: PROFINET
- CM-Ethernet/IP: Ethernet/IP with one usable port as end-of-line device
- CM-Ethernet/IP-2P: Ethernet/IP with two usable ports (daisy chaining is possible)
- CM-Modbus/TCP: Modbus/TCP with one usable port as end-of-line device
- CM-Modbus/TCP-2P: Modbus/TCP with two usable ports (daisy chaining is possible)
- Ethernet VABus/TCP: VABus/TCP: with one usable port as end-of-line device
- Ethernet VABus/TCP-2P: VABus/TCP: with two usable ports (daisy chaining is possible)
Optional interface for communication to PC
- ASK-USB: Communication to PC via optional communication cable
Optional PC software
- VPlus for Windows operating system with motor setup, terminal monitor
- Actual value window, scope function, parameter storage
Accessories:
- Brake resistors Type BR: The brake resistors offer an inexpensive solution to dissipate generator power that occurs at deceleration. A thermal sensor for the brake resistor protects the resistor from overheating.
- Power choke type LCVS & LCVT: Power choke types LCVS (for single-phase power installation) and LCVT (for three-phase power installation) increase the overvoltage protection of the inverter and increase the system's EMC.
- Power filters type FTV: Depending on the application boundaries, certain EMC levels must be achieved. The power filters are a component to improve EMC behavior in a machine installation.
Power supply & Power range
Power range (AGL402)
0.25 - 11 kW / three-phase 320 V... 530 V / 50 - 60 Hz (± 10%)

Power range (AGL202)
0.12 - 3 kW / single-phase 200 V... 240 V / 50 - 60 Hz (± 10%)
0.25 - 7.5 kW / three-phase 200 V ... 240 V / 50 - 60 Hz (± 10%)
Hardware features
- Integrated Keypad
- Integrated brake chopper
- Integrated Safe Torque Off function
- DC link connection
- 6 digital inputs, 2 multifunction A/D inputs
- 1 digital output, 1 multifunction I/O
- 1 relay output, 1 multifunction A/D/Pulse output
- Signal supply outputs: +24 V DC, + 10 V DC
+24 V DC input for electronic power supply
- Serial interfaces: RS-232, RS-485 including Modbus support
system bus
Software features
- Preset values for Bonfiglioli motors to decrease commissioning times
- Flexible assignment of digital inputs and outputs
- Energy Saving function
- Ready to use application macros
- Motor chopper function to increase braking power without brake resistors
- Power failure regulation
- Fault history
- Motor and inverter state memory
- Integrated PLC function with graphic development environment
Power range
• AGL202: 0.12 - 3 kW / single-phase 200 V... 240 V / 50 - 60 Hz (± 10%) 0.25 - 7.5 kW / three-phase 200 V ...240 V / 50 - 60 Hz (± 10%)
• AGL402: 0.25 - 11 kW / three-phase 320 V... 530 V / 50 - 60 Hz (± 10%)
Mounting options
• Cabinet mounting for all sizes
• Optional feed-through mounting
• Optional DIN rail mounting frame
Motors
- Motor compatibility
- Two types of motors:
- Asynchronous AC motors
- Permanent magnet synchronous (brushless) motors
Motor options
Motor Control(open loop):
• Asynchronous AC motors
• Permanent magnet synchronous (brushless) motors

Types & Powers

Type	kW (three-phase)
AGL402-02 1	0.25
AGL402-03 1	0.37
AGL402-05 1	0.55

Types & powers (AGL402)

Type	kW (three-phase)
AGL402-07 1	0.75
AGL402-09 1	1.1
AGL402-11 1	1.5
AGL402-13 1	2.2
AGL402-15 2	3.0
AGL402-18 2	4.0
AGL402-19 2	5.5
AGL402-21 2	7.5
AGL402-19 3	5.5
AGL402-21 3	7.5
AGL402-22 3	9.2
AGL402-23 3	11

Types & powers (AGL202)

Type	kW (three-phase)
AGL202-02 1	0.25
AGL202-03 1	0.37
AGL202-05 1	0.55
AGL202-07 1	0.75
AGL202-09 1	1.1
AGL202-11 1	1.5
AGL202-13 1	2.2
AGL202-15 2	3.0
AGL202-18 2	4.0
AGL202-19 3	5.5
AGL202-21 3	7.5

Types & powers (AGL202)

Type	kW (single-phase)
AGL202-02 1	0.12
AGL202-03 1	0.18
AGL202-05 1	0.25
AGL202-07 1	0.37
AGL202-09 1	0.55
AGL202-11 1	0.75
AGL202-13 1	1.1
AGL202-15 2	1.5
AGL202-18 2	2.2
AGL202-19 3	3
AGL202-21 3	3
