Engineering Solutions for Commercial Electric Lawn Care Equipment
A Technical Analysis of Integrated Drive Systems
Electrifying commercial lawn care equipment presents unique challenges requiring specialized solutions. This analysis highlights how Bonfiglioli’s advanced integrated drive systems optimize performance, emissions compliance, and durability for demanding applications.
Key Features of the 700CE Series with BPM240 Motor
700CE Planetary Drive: Engineered for Excellence
Wide Gear Ratio Range: Offers optimal motor speed control for achieving precise blade tip velocity and superior cutting performance.
Rugged Cast Iron Housing: Ensures durability in challenging outdoor environments, providing impact resistance and long-term reliability.
Advanced Bearing Design: Engineered for extended service life, even under continuous heavy-duty operation.
BPM 200 Series Electric Motors: High-Performance Power
Permanent Magnet Synchronous Motor (PMSM): Delivers superior power density and efficiency.
Nominal Voltage Range: Operates efficiently within a 48-650 Vdc range, ensuring compatibility across various applications.
Power Range: Nominal power output of 5.3-13.5 kW, catering to diverse cutting deck sizes.
Peak Torque: Delivers torque between 60-190 Nm for high-performance operation.
Maximum Speed: Reaches up to 6000 rpm for exceptional cutting efficiency.
Additional Features BPM200 Motor
Integrated High-Accuracy Temperature Sensor: Ensures reliable thermal monitoring for enhanced durability.
High-Resolution Hall Effect Speed Sensor: Enables precise speed feedback and control.
Manual Disengagement Feature: Simplifies maintenance and enhances operational flexibility.
Integrated Electromagnetic Brakes: Provides secure and efficient stopping power.
Protection Rating: Offers IP65 or IP67 options to meet varying environmental demands.
Integrated Systems
Combining planetary drives and electric motors for seamless operation and reduced system complexity.
Scalability
Customizable power solutions to match specific mower sizes and operational requirements.
Efficient Supply Chain
A single supplier model that reduces lead times and ensures quality across components.
Technical Expertise
Decades of engineering knowledge to support OEMs in optimizing their designs for electromobility.
Designing for the Future:
Electric mowers equipped with Bonfiglioli systems offer several key advantages:
Environmentally Friendly: Zero emissions to meet evolving regulatory standards and reduce the carbon footprint.
Quieter Operation: Minimal noise for enhanced operator and neighborhood comfort.
Lower Total Cost of Ownership: Virtually maintenance-free components result in long-term savings.
Enhanced Efficiency: High energy conversion rates and optimal power management extend runtime and reduce energy consumption.
Partnering with Bonfiglioli
As a global leader in electromobility solutions, Bonfiglioli is committed to supporting OEMs and design engineers in developing cutting-edge, sustainable equipment. With our 700CE and BPM 200 series, you can create high-performance electric mowers that redefine efficiency, reliability, and environmental complian
